F-K BEARINGS INC. SJNR05 MODELS

Need a CAD or 3D Model?

Plain Bearings SJNR05

Name: Plain Bearings SJNR05
Brand: F-K BEARINGS INC.
SKU: SJNR05
Rating: 4.9 (5 reviews)

Agicb industrial parts LLP

Agicb industrial parts LLPChina

Agicb industrial parts LLP2020-07-10 09:46:19
Welcome to my shop! Glad to serve you! Please send your question!

Interested In: Price Inspection Certificate Product Specifications Company Profile

F-K BEARINGS INC. SJNR05 bearing Size Chart (mm/inches)
Engineering Group	Mounted Bearing
Bearing Number	22209
Shaft Size	45 mm
Shaft Size Type	Metric
Full Timken Part Number	QMSN09J045SB
Locking Style	Eccentric
Weight	23 lb
Housing Style	Two-Bolt Pillow Block
UPC Code	0883450096126
Dimension A	2.36 in
Dimension B	4.370 in
Dimension C	2.64 in
Dimension D Max	6.89 in
Dimension D Min	6.26 in
Dimension F	8.07 in
Dimension G	2.440 in
Dimension H	1.38 in
Dimension J (Bolt Size)	0.500 in
Dimension K	0.98 in
Dimension L	3.11 in
Dimension M	1.89 in
Dimension R	0.24 in
Dimension S	2.87 in
C0 - Static Load	24200 lb
C - Dynamic Load (Basic)	24500 lb
e - Geometry Factor	0.26
Y1 - Geometry Factor	2.64
Y2 - Geometry Factor	3.93
Oil Lubrication - M/N Seal	2700 rpm
Oil Lubrication - T Seal	4500 rpm
Oil Lubrication - B/C/O Seal	1950 rpm
Grease Lubrication - M/N Seal	2700 rpm
Grease Lubrication - T Seal	4000 rpm
Grease Lubrication - B/C/O Seal	1950 rpm
Float	0.050 in
Shaft Tolerance	0.0015 in
Eng Internal Radial Clearance - Min	0.0014
Eng Internal Radial Clearance - Max	0.0022
Pre Install Clearance Min	0.0014 in
Pre Install Clearance Max	0.0022 in

Plain Bearings Part series SJNR05 is a potential replacement for these common bearing part numbers:
